DIN-Rail Gigabit Switches
Ethernet Direct offers a complete range of industrial DIN-rail switches from unmanaged Ethernet switch and managed Ethernet switch that support Gigabit and fast Ethernet options with copper/fiber connectors.
Ethernet Direct offers SNMP Full Gigabit Managed DIN-rail switches with 8/11/20 port density. The new Husky switches are designed with advanced Layer 2 management features and certified by strict agency approvals suitable for specialized industries & solutions.
HMG-448G / HMG-628G
- Supports 12~48VDC power inputs
- Supports STP, RSTP, Dual Homing & Couple ring redundancy
- Proprietary protocol X-Ring with < 10 ms recovery time
- DHCP Server/Client, SNMP / RMON network management, VLAN configuration, IGMP snooping, QoS
- Flexibility security: Port based and MAC based IEEE802.1X, RADIUS
- Software upgrade via TFTP
- CLI, Web based management, SNMP, Telnet server for management
HMG-448GEPT / HMG-838GEPT / HMG-8128GEP / HMG-1648GEP series
High Performance Network Switching Technology
- Complies with IEEE standards
- Provides multiple Gigabit TX ports with RJ-45 connector with supporting of Green Ethernet IEEE802.3az EEE (Energy Efficient Ethernet)
- Provides multiple Gigabit SFP slots with supporting of DDMI
- Supports various network redundant solutions, including Direct-Ring, Direct-Chain, Join-Ring, STP, RSTP, MSTP and ITU-T G.8032
- Proprietary ultra high speed redundant technology with < 10ms recovery time @ 250 devices
- Supports IEEE1588 PTP V2 for precise time synchronization, to operate in Ordinary-Boundary, Peer to Peer Transparent Clock, End to End Transparent Clock, Master, Slave mode by each port
- Supports various network security solutions, Port and MAC based IEEE802.1X, RADIUS, ACL, TACACS+, HTTP/HTTPS, SSL/SSH v2
- Supports DHCP Server/Client/Relay/Snooping/Snooping option 82/Relay option 82
- Network traffic priority, QoS, Traffic classification QoS, CoS, bandwidth control for Ingress/Egress, broadcast storm control, DiffServ
- Supports IEEE802.1Q VLAN, MAC-based VLAN, IP Subnet-based VLAN, Protocol-based VLAN, VLAN translation, GVRP/MVRP
- Supports IGMP/MLD snooping V1/V2/V3, IGMP Filtering/Throttling, IGMP query, IGMP proxy reporting, MLD snooping
- Supports dynamic IEEE 802.3ad LACP Link Aggregation, Static Link Aggregation
- Supports RMON, MIB II, Port mirroring, Syslog, IEEE802.1ab LLDP for network monitoring
- Supports IPv6 Telnet server, ICMPv6
- Supports CLI, Web based management, SNMP v1/v2c/v3, Telnet server for management
- Supports firmware upgrade via TFTP & HTTP with redundant firmware option
Reliable Power Design
- Supports 12 to 48VDC redundant power input
- Power reverse polarity protection and overload current protection
Robust Industrial Design
- UL60950-1, CE, FCC certified
- EN 61000-6-2 and EN 61000-6-4 certified to use in heavy industrial environment
- NEMA TS-2 certified for Traffic Control
- EN 50121-4 certified for Railway Applications (Track Side)
- Robust industrial design case complies with IP30 housing standard
- Supports operating temperature -10 to 70°C & extended temperature -40 to 80°C
- DIN-Rail or optional wall mounting installation
Prodcut Features
Ethernet Direct offers Plug and play industrial unmanaged switches that provide an economical solution for your industrial Ethernet connections and can be installed easily on a DIN-rail or in a distribution box.
High Performance Network Switching Technology
- Complies with IEEE standards
- Provides multiple Gigabit TX ports with RJ-45 connector
- Provides multiple Gigabit SFP slots or SC connectors
- Supports IEEE 802.3az Green Etherent (EEE / Energy Efficient Ethernet)
- Provides DIP switch to switch on/off of the alarm relay, broadcast storm protection, green Ethernet and setting up the transmission speed of the SFP slot
Reliable Power Design
- Supports 12 to 48VDC redundant power input
- Power reverse polarity protection and overload current protection
Robust Industrial Design
- UL60950-1, CE, FCC certified
- EN 61000-6-2 and EN 61000-6-4 certified to use in heavy industrial environment
- EN 50121-4 certified for Railway Applications (Track Side)
- Robust industrial design case complies with IP30 housing standard
- Supports operating temperature -10 to 70°C & extended temperature -40 to 80°C
- DIN-Rail or optional wall mounting installation
